PRV Audio 8MB500-4 8" 4 ohm Car Speaker (Single) | 500W RMS

The 8MB500-4 8" Midbass Speaker is built for powerful performance and long-lasting durability. Engineered to deliver deep, punchy midbass, this professional loudspeaker is perfect for home audio systems and car door speaker upgrades alike. Designed to reproduce the critical low-frequency range with clarity and strength, the 8MB500-4 is a top choice for high-performance sound systems in both home and car audio applications.

• Deep, punchy midbass and crisp vocal clarity for powerful, balanced sound

• Pro audio 8" midbass woofer with smooth low-frequency response and impactful midbass punch

• Natural paper cone and cloth triple-roll surround for accurate and smooth sound reproduction

• 500-watt power handling ensures reliable performance at high volume levels

• Perfect for high-output car audio, home theater, and professional sound systems with 4 Ohm impedance

Built with premium components for high-fidelity sound performance, this midbass speaker features compact push terminals, silver tinsel lead wires, and a high-temperature CCAW voice coil for maximum efficiency and durability.

Utilizing advanced magnetic field technology, it delivers powerful performance without the need for a bulky magnet. The large-diameter motor structure offers impressive power handling in a compact design, making this midbass woofer both space-efficient and high-performing — a perfect choice for demanding car and home audio setups.

Engineered for high-performance audio systems, this professional midbass speaker features a naturally damped paper cone and a specially coated dust cap for smooth, accurate sound across a wide frequency range of 75 Hz to 7,500 Hz — ideal for use in three-way speaker systems.

Perfectly suited for tight enclosures, the cloth triple roll surround allows for linear cone movement, even at high excursion levels. This optimized cone and suspension design ensures clear vocal reproduction and powerful midbass response, making it an excellent choice for car audio, home audio, and professional sound reinforcement systems.

GENERAL SPECIFICATIONS

- *Nominal Power Handling:* Defined as the maximum RMS power the speaker can handle over a 2-hour test with pink noise featuring a 6dB crest factor and a bandpass filter with 12dB/oct tuned to its usable frequency range.

- **Continuous Program Power (RMS):** The maximum power the speaker can handle during a regular musical program using our recommended filters. This rating helps define the optimal amplifier power to provide a clean signal without clipping or saturation.

- ***Max Peak Power:** The highest power level the speaker can handle for brief moments, typically during music peaks. Sustaining this power for longer periods will damage the speaker.

THIELE-SMALL PARAMETERS

***Xmax = (Voice coil winding depth - Magnetic Gap depth) / 2 + Magnetic Gap Depth / 4

EXTRA INFO

PRV AUDIO 8MB500-4 DATASHEET
