SMD SMD-5000.1D Monoblock Amplifier

Description

SMD SMD-5000.1D Amplifier Monoblock | 5000W RMS

The SMD SMD-5000.1D Monoblock Amplifier is a powerhouse designed by Steve Meade Designs in collaboration with DS18. Engineered for exceptional performance, this 5000W RMS amplifier delivers unmatched power and precision for audiophiles and competitors alike. Its compact yet robust design features premium Korean components, ensuring reliability and clean, powerful bass.

Key Features:

5000W RMS Power: Delivers 2000W @ 4 ohms, 3500W @ 2 ohms, and 5000W @ 1 ohm.
Exclusive Design: Features a clear half-top acrylic window and customizable RGB LED lighting with remote control.
Integrated VM-1 Voltmeter: Real-time monitoring of power draw with a digital/analog-style display.
Efficient Cooling: Reverse-mounted board and dual cooling fans for optimal heat dissipation.
Professional Build: Includes Tiffany RCA terminals, 0 AWG inputs, and OFC internal wiring.
Advanced Protection: Safeguards against thermal overload, DC output, short circuits, and voltage input issues.

Superior Performance & Efficiency

As a Class D amplifier, the SMD-5000.1D prioritizes energy efficiency and low heat production while maintaining a <0.02% Total Harmonic Distortion (THD) for clean, distortion-free audio. With a frequency response of 15Hz-270Hz and a Fixed LPF, it provides optimal sound control and precision tuning for deep, dynamic bass.

Built for Serious Bass Enthusiasts

The SMD-5000.1D combines cutting-edge technology, sleek design, and raw power to meet the demands of high-performance subwoofer setups. Whether for daily driving or competition, this amplifier is built to handle it all with ease.

Upgrade your car audio system with the SMD SMD-5000.1D Monoblock Amplifier and experience superior sound quality, durability, and style.

Manual - Technical Data

Exclusive SMD design with VM-1 voltmeter

Front acrylic window and digital RGB lighting

IR remote control for LED patterns and colors

Professional Tiffany
RCA terminals

Dual cooling fans <br> For Enhanced Performance

Dual cooling fans
For Enhanced Performance

Korean components <br> OFC Internal Wiring

Korean components
OFC Internal Wiring

SPECS	AUDIO	FEATURES	MEASUREMENT
SKU SMD-5000.1D RMS Power @ 4 ohm (14.4v) 2000W RMS Power @ 2 ohm (14.4v) 3500W RMS Power @ 1 ohm (14.4v) 5000W	Frequency Response 15Hz-250Hz Signal to Noise Ratio >98dB Efficiency @ 4ohm >86% Damping Factor 300 Input Impedance 22K ohm Total Harmonic Distortion (THD) <0.02% Low Level Input Range 200mV-6V High Level Input NO Selectable X-Over Fixed LPF X-Over Filter Range 35Hz-250Hz Bass Boost Range 0~9dB Bass Boost Frequency 30Hz-60Hz Infrasonic Filter 10Hz-30Hz Phase Selector 0~180	Amplifier Class Digital Amplifier Type Subwoofer Number of Channels 1 Minimum Impedance 1 ohm Led Indicator Power / Protection / Clip Power Input Terminal Size 0 AWG Recommended Fuse Size (Not Included) 520A Cooling Fan Yes Thermal Protection Yes Over-Load Protection Yes DC Output Protection Yes Short Circuit Output Protection Yes Voltage Input Protection Yes Clipping Protection Yes Body Color / Finish Black Metal Adjustment Knobs with Click Position Yes Professional Tiffany RCA Connectors Yes Remote Level Knob with Clip indicator Yes (Metal Case) Linkable (Strap mode) Amplifier Yes Reliable Heavy Duty Korean Board Design Yes Very High Efficiency Digital Circuit Design Yes Exclusive SMD design with VM-1 Voltmeter Yes Front Acrylic Window and Digital RGB Lighting Yes IR Remote Control for LED patterns and colors Yes	Overall Length 18.1" / 462mm Overall Width 9.15" / 232mm Overall Height 3" / 76mm Heatsink Length 16.5" / 420mm Gross Single Unit Weight 15Lb / 6.8kg

* Manuals and/or specifications are subject to change without prior notice.
